Casio CTX 9000 IN

Description

Keyboard : 61 standard size keys Touch Response: Sensitivity 3 types, Off Maximum Polyphony 64 notes (32 for certain tones) Tones Preset Tones: 800 (43 Indian) User Tones: 100 Other: Layer, split (configurable split point, lower point, chord point settings) System Effects Reverb: 32 types, Off Chorus: 16 types, Tones Delay: 20 types, Tones DSP: 100 types (Can be applied to user tones using DSP editing.), DSP tones Master Effects Equalizer (10 presets) 4-band User Equalizer External Input Effects Center cancel (vocal cut) for input from the Audio In jack Metronome Beat: 0 (accented tone off), 1 to 16 Tempo: Tempo value: 20 to 255 Demo Songs 3 Song Bank Built-in Songs: 30 User-recorded Songs: 10 USB Memory Songs: Playback of standard MIDI files (SMF format 0/1), CASIO MIDI files (CMF format) on a USB flash drive is supported. USB Audio Playback Playback of audio files on a USB flash drive is supported. Supported File Formats: WAV format, 44.1 kHz 16 bit Other Functions: Center Cancel (Vocal Cut) Auto Accompaniment Built-in Rhythms: 250 (39 Indian) User Rhythms: 100 One Touch Presets: 250 Music Presets 310 (With chord progressions) Phrase Pads Number of Pads: 4 User Phrases: 100 (4 phrases x 25 pads) Editing Mode: Copy, delete, phrase editing Mixer function Affected Parts: Sound source parts, microphone input part Parameters: Part on/off, volume, pan, reverb send, chorus send, delay send Registration Maximum 128 setups (8 setups x 16 banks), registration sequence Tone Editing Preset tone editing, DSP editing Memory for storage of edited tones (up to 100) Rhythm Editing New rhythm creation, rhythm editing Memory for storage of created/edited rhythms (up to 100) MIDI Recorder Real-time recording, playback Keyboard Performance Recording: 10 songs, 17 tracks (1 system track, 16 solo tracks) Memory Capacity: Approximately 40,000 notes (per song) Editing Mode: Song editing, track editing, event editing, step input Other Functions: Overdubbing, punch-in recording Pedals Sustain, sostenuto, soft, rhythm/song, expression Controllers Pitch bend wheel, TOUCH ON/OFF button, PORTAMENTO button, MODULATION/ASSIGNABLE button Other Functions Transpose: ±1 octaves (-12 to 0 to +12 semitones) Octave Shift: Upper 1/Upper 2/Lower 1/Lower 2, ±3 octaves Tuning: A4 = 415.5 to 465.9 Hz (Initial Default: 440.0 Hz) Part coarse tune: For each keyboard part, ±2 octaves (-24 to 0 to +24 semitones) Part fine tune: For each keyboard part, ±99 cents Scales: 17 preset scales, scale fine tuning Auto Harmonize: 12 types Arpeggiator: 150 types SFX: 57 MIDI 16ch multi-timbre received, GM Level 1 standard Inputs/Outputs USB Flash Drive Port: Type A USB Port: Type B Pedal 1 Jack: Standard jack Pedal 2, Expression Jack: Standard jack Headphones Jack: Stereo standard jack Audio Input Jack: Stereo mini jack/Input impedance 9 kΩ, Input sensitivity 200 mV Line Out Jack: Standard jacks x 2/Output impedance 2.3 kΩ, Output voltage 1.9 V (RMS) MAX Microphone Input Jack: Standard jack (Connect a dynamic microphone.)/ Input impedance 3 kΩ, Input sensitivity 10 mV Power Jack DC 24V Power Supply AC adaptor only AC Adaptor: AD-E24250LW Auto Power Off: Approximately 30 minutes after last operation; Can be disabled. Speakers 10cm x 2 (Output: 15W + 15W) Power Consumption 15 W Dimensions W 94.8 x D 38.4 x H 11.6 cm Weight Approximately 7.0 kg
