M Audio Air 192X4

Description

Key Features: • 24-bit/192kHz resolution for professional recording and monitoring • Hi-Speed USB circuitry gives you the fastest connection, with a class-leading round trip latency of only 2.59ms* • Transparent Crystal™ preamps and ultra-pristine A/D converters for unsurpassed audio recording quality • VU LED meters for dialing in the perfect level • XLR+¼” TRS combo input with dedicated signal circuit and (1) ¼” instrument input with dedicated signal circuit for the most accurate sound available • Stereo ¼” outs; ¼” headphone out with independent level control • Rugged metal chassis; large central control for easy volume adjustment • USB/Direct knob for balancing between the input signal and the computer signal *Round trip latency is dependent on buffer settings, and computer hardware Specifications: Minimum System Requirements: • macOS: 10.8 Class Compliant • PC: Windows 7, Windows Driver • Standard USB 2.0 or USB-C Port Mic Input 1 (balanced XLR) FREQUENCY RESPONSE: 20 Hz – 20 kHz (+0.1 dB) DYNAMIC RANGE: 104 dB (A-weighted) SIGNAL-TO-NOISE RATIO: 104 dB (+1.0 dBu, A-weighted) THD+N 0.003% PREAMP EIN: -128 dBu (max gain, 150 Ω source, A-weighted) MAX INPUT LEVEL: +1.5 dBu GAIN RANGE: 55 dB Line Input 1 (balanced 1/4" [6.35 mm] TRS) FREQUENCY RESPONSE: 20 Hz – 20 kHz (+0.05 dB) SIGNAL-TO-NOISE RATIO 101 dB (1 kHz, +4 dBu, A-weighted) THD+N 0.003% MAX INPUT LEVEL: 16 dBu GAIN RANGE: 55 dB Inst Input 2 (unbalanced 1/4" [6.35 mm] TS) FREQUENCY RESPONSE: 20 Hz – 20 kHz (+0.05 dB) DYNAMIC RANGE: 100 dB (A-weighted) SIGNAL-TO-NOISE RATIO: 102 dB (+ 4 dBu, A-weighted) THD+N 0.004% MAX INPUT LEVEL: 6 dBu INPUT IMPEDANCE: 1 MΩ GAIN RANGE: 24 dB Main Outputs, L and R (balanced, differential 1/4" [6.35 mm] TRS) FREQUENCY RESPONSE: 20 Hz – 20 kHz (+0.06 dB) DYNAMIC RANGE / SIGNAL-TO-NOISE RATIO: 102 dB (A-weighted) THD+N 0.005% MAX OUTPUT LEVEL +7 dBu (1 kHz, -1 dBFS) Headphone Output: (impedance-balanced 1/4” [6.35 mm] TRS) THD+N 0.005% OUTPUT IMPEDANCE 10 Ω General: POWER USB-bus-powered: DIMENSIONS (WIDTH X DEPTH X HEIGHT) 8.0” x 6.0” x 2.76” (20.42 cm x 15.24 cm x 7.0 cm) WEIGHT 2.0 lbs. 0.9 kg
